Features
- Powerful 15.0 AMP motor delivers 5,800 RPM for proven performance and jobsite durability
- Lower guard design improves performance when making bevel and narrow cuts
- Large cutting capacity (2-3/8" at 90°, 1-3/4" at 45°)
- Two built-in L.E.D. lights illuminate the line of cut for increased accuracy
- Well balanced design for superior handling and performance
- Heavy gauge aluminum wraparound base engineered for improved durability and straighter cuts
- Built-in dust blower clears the line of cut for greater accuracy
- Technologically-advanced centrifugal fan and baffle system for efficient cooling of the motor
- Bevel cuts 0-45° for the most common angles
- Large and easy-to-read markings on depth and bevel scales
- Flat motor housing design increases stability when changing blades
- Conveniently located shaft lock for easy blade replacement
- AC/DC switch allows for use with alternative power sources
- All-ball bearing construction engineered for longer tool life
- Ideal for framers, builders, masons and siding contractors
- Double insulated
Specifications
| Blade Diameter |
|
7-1/4" |
| Arbor |
|
5/8" |
| No Load Speed |
|
5,800 RPM |
| AMPS (115V) |
|
15.0 |
| Max Cutting Capacity |
at 90° |
2-3/8" |
| |
at 45° |
1-3/4" |
| Net Weight (lbs.) |
|
11.1 |
Includes
- 24T Carbide tipped blade (D-24826)
- Blade wrench (783204-6)
Contact us for warranty information |
