| Additional Information |
Features
- Oil-lubricated pump with cast iron cylinders provides over 1,500 hours of running life
- 125 max PSI enables more nails to be fired and provides a quicker recovery
- Dual soft start valves assist in cold weather start-up
- Site glass and dip stick for easy check of oil level
- 10-in pneumatic wheels and collapsing handle for ease of mobility and storage
- Top load panel allows unit to transport up to 100 lbs. of cargo
- Dual universal push-to-connect couplers easily support two users
- Ball drain valve for quick and thorough tank draining
Specifications
| Length: |
18 in. |
Drive System: |
Direct Drive |
| Width: |
18.5 in. |
Fitting Type: |
NPT |
| Height: |
16.75 in. |
Horsepower: |
1.1 |
| Weight: |
95 lbs. |
Lubrication: |
Oil-Lube |
| AC Voltage: |
120V |
Operating Pressure - PSI: |
125 |
| Air Consumption at 40 PSI - SCFM: |
3.8 |
Power Type: |
Electric |
| Air Consumption at 90 PSI - SCFM: |
4 |
Pump Type: |
Cast Iron |
| Air Inlet Size: |
1/4 in. |
Tank Capacity: |
4 gal. |
| Amperage: |
15 |
Tank Construction: |
Cast Iron |
Contact us for warranty information |
