Features
- Powerful 15.0 AMP motor delivers 5,800 RPM for proven performance and jobsite durability
- Magnesium components create a lightweight saw (10.6 lbs.) that is well balanced and jobsite tough
- Make quick, one-handed adjustments using large, rubberized levers
- Better fit and more control with comfortable rubber grip on handle
- Settings are easy to read with oversized number and ruler markings
- Large cutting capacity (2-1/2" at 90°) and bevel capacity (0°-56°) with positive stops at 22.5°and 45°
- Two built-in L.E.D. lights illuminate the line of cut for increased accuracy
- Built-in dust blower clears the line of cut for greater accuracy
- Blade wrench is attached to saw for fast and convenient blade changing
- Reinforced power cord withstands jobsite abuse and lowers repair costs
- Includes a premium 7-1/4" carbide tipped framing blade that cuts 50% faster and lasts 2x longer
Specifications
| Blade Diameter |
7-1/4" |
| Arbor |
5/8" |
| Max Cutting Capacity: |
| 90° |
2-1/2" |
| 45° |
1-3/4" |
| 56° |
1-3/8" |
| No Load Speed |
5,800 RPM |
| Watts Out |
2,300 |
| AMPS (120V) |
15.0 |
| Overall Length |
12-1/2" |
| Net Weight (lbs.) |
10.6 |
Includes
- 24T Carbide Tipped Blade (A-94530)
- Blade Wrench (783204-6)
- Rip Fence (164095-8)
- Tool Case (824772-1)
