| Additional Information |
Features
- HolsterTop with Lock-In System secures tools to increase productivity
- Shoulder bolt and nut on top hinge
- 4 rivets attach top to each front rail
- Double riveted slip-resistant TRACTION-TRED® steps
- Back-up plates reinforce all top connectors
- Heavy duty internal spreaders
- Full set of rear horizontals spaced one per foot
- All steps and two rear horizontals are knee-braced
- Slip-resistant foot pads attached to the EDGE® structure
- Every rivet backed up by metal, metal plates or washers to protect rails
- Optional manual pail shelf kit, model no. PK76-9 or automatic closing pail shelf kit model no. 76-2
Specifications
| Size |
8 ft |
| Reach Height |
12 ft |
| Max. Standing Height |
5 ft 9 in |
| Edge Bracing |
Heavy |
| Load Capacity |
300 lbs |
| Type |
Type IA Duty Rating |
| Material |
Fiberglass |
| Approx. Width |
26-7/8 in |
| Approx. Spread |
53-5/8 in |
| With Pail Shelf |
No |
| Spreader Material |
Steel |
| Certifications |
ANSI A14.5 (2007); OSHA |
| Approx. Cu. Ft. Per Unit |
8.1 |
Contact us for warranty information |
