Features
- 150 max PSI 6.0 gallon tank (22.7 L) and 2.6 SCFM* delivered @ 90 PSI pump, enable long tool run time with quick recovery
- Long life oil free, maintenance free pump for convenient use
- BOSTITCH® high efficiency motor for easy start up in cold weather or extension cord application [14 GA or larger, 50 ft. (15.2 m) or less]
- 80 dBA** operational noise level for a quiet work environment
- 33 lb weight and narrow 14" tank diameter make unit easy to carry and store
- BOSTITCH® high flow regulator and couplers to maximize air tool performance
- Two universal couplers to easily support two users
- Controls are inset in shroud to provide protection
- Console cover is removable to allow easy repair of controls
- Convenient cord wrap for easy storage
- Ball drain valve allows for quick and thorough tank draining
Specifications
| AC Voltage: |
120V |
| Air Consumption at 40 PSI - SCFM: |
3.7 |
| Air Consumption at 90 PSI - SCFM: |
2.6 |
| Air Inlet Size: |
1/4 in. |
| Amperage: |
15 |
| Fitting Type: |
NPT |
| Lubrication: |
Oil-Free |
| Noise Rating - dBA: |
80 |
| Operating Pressure - PSI: |
150 |
| Power Type: |
Electric |
| Tank Capacity: |
6 gal. |
| Tank Construction: |
Aluminum |
| Tank Orientation: |
Vertical |
| Tank Style: |
Pancake |
Contact us for warranty information |
