| Additional Information |
Features
- Soft-starting, 12 Amp motor features full-time electronic feedback that maintains motor speed through the toughest applications
- Variable-speed control feature (10,000 - 23,000 rpm) enables bit speed to be optimized for changing applications
- Release the motor, adjust bit height, and clamp the motor from above the router table with 3/16" hex socket (sold separately) or model # 75301 kit (sold separately). GripVac™ base only
- Dual-position switch allows user to cut power while maintaining control of the router
- Overmolded grips for greater comfort in extended use
- Spindle lock feature allows for single wrench bit changes
- Durable latch lever enables quick and simple coarse depth adjustments and motor release for transition between bases
- Rack and pinion adjustment provides fine depth settings to 1/128"
- Collets included to accept 1/4" and 1/2" shank bits
- Motor transitions quickly between bases
Specifications
| Power: |
120V AC, 60 Hz |
| Amps: |
12 Amps |
| Horsepower: |
2-1/4 HP |
| No Load Speed: |
10,000 - 23,000 rpm |
| Motor Diameter: |
3-1/2 " |
| Collets: " |
1/4" & 1/2" |
| Base: |
Round |
| Length: |
9 " |
| Width: |
6 " |
| Height: |
At Zero: 9.9"; Tallest: 11.1 " |
| Weight: |
9 lbs |
Includes
- 8902 router motor
- 8901 fixed base
- 1/4" & 1/2" collets
- Collet wrench
- Carrying case
- Operating manual
Contact us for warranty information |
