Features
- 7.5 Amp; 0-1,300 RPM; 0-5,800 BPM
- HammerHook™ allows quick tool storage during the job.
- Multi-function Selector — 3 modes of operation, rotation only, rotary hammer and hammer-only mode
- Vario-Lock™ positioning — rotates and locks chisel into 36 different positions to optimize working angle
- Patented Rotating Brush Plate — Provides equal power in forward and reverse
- Patented Cord Turret — 35° pivot for added flexibility and longer cord life
- SDS-plus® bit system — tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate
- D-Handle design — Ideal for overhead and downward drilling applications
- Variable-speed Reversing Trigger — For accurate bit starting as well as removing fasteners or bound bits
- Integral clutch — helps minimize torque reaction
Specifications
| Amperage |
7.5 |
| Certifications |
CSA |
| Cord Length |
8 ft |
| Height |
6" |
| Impact Energy/EPTA (ft. lbs.) |
2.2 |
| Length |
17.25" |
| Max. Hole Diameter in Concrete |
1" |
| Max. Hole Diameter in ConcreteThin Wa |
2-5/8" |
| Max. Hole Diameter in Steel |
1/2" |
| Max. Hole Diameter in Wood |
3/4" - 1" |
| No Load BPM |
0 - 5,800 |
| No Load RPM |
0-1,300 |
| Optimal Concrete Capacity Range |
3/16" - 5/8" |
| Rating |
120V |
| Voltage |
120V |
| Weight |
6.7 lb |
Includes
- Auxiliary Handle -- 2 602 025 141
- Depth Gauge -- 1 613 001 010
- Carrying Case -- 2 610 994 810
