Features
- Exclusive ALFLO® rung joint means TWIST-PROOF® performance
- 1-5/8in Slip-resistant TRACTION-TRED® D-rungs
- Smooth operating pulley with polypropylene rope
- Interlocking Side Rails with internal rail guides on bottom of fly section securely connect rails
- External guides at top of base section securely interlock rails
- Heavy Duty extruded rung locks are spring loaded to operate smoothly
- Pre-pierced holes for easy field installation of accessories
- Base and fly separate easily to use base section as single ladder
- Combination Rail Shield Bracket and Shoe with SHU-LOK® and Slip-Resistant Pad
- Molded Rung Braces on bottom step for increased durability
- Mar-Resistant Molded End Caps
Specifications
| Reach Height |
27ft |
| Max Working Length |
25ft |
| Extended Length |
25ft |
| Style |
Multi Section |
| Load Capacity |
300 lbs |
| Type |
Type IA Duty Rating |
| Material |
Fiberglass |
| Rung Type |
D |
| Foot Material |
Slip-resistant pad |
| Number of Sections |
2 |
| Base Width |
19in outside shoes |
| Certifications |
ANSI A14.5 (2007); OSHA |
| Approx. Cu. Ft. Per Unit |
12 |
| Approx. Shipping Wt. Lbs. |
59.5 |
Contact us for warranty information |
