Features
- Exclusive ALFLO® rung joint means TWIST-PROOF® performance
- 1-3/4" Slip-resistant TRACTION-TRED® D-rungs
- Heavy Duty extruded rung locks are spring loaded to operate smoothly
- Base and fly separate easily for use as an extension or two single sections
- Smooth operating pulley design – enclosed shape protects pulley
- Guide brackets mounted at the top and bottom of the rail for durability and smooth operation of fly section
- Extra heavy duty I-beam rails
- Rugged spring loaded locks operate smoothly
- Rugged shoe rests flat or is held in spur position with SHU-LOK® feature
- Stacked rail design provides increased rung width on fly section
- Mar-resistant end caps
Specifications
| Feature |
Size / Details |
| Size |
36' |
| Reach Height |
34' |
| Max Working Length |
32' |
| EXTENDEDLENGTH_EL |
21' |
| Style |
Multi Section |
| Load Capacity |
300 lbs. |
| Type |
Type IA Duty Rating |
| Performance Rating |
|
| Material |
Aluminum |
| Rung Type |
D |
| Foot Material |
Slip-resistant pad |
| Number of Sections |
2 |
| Base Width |
18-1/8" outside rails |
| Certifications |
ANSI A14.2 (2007); OSHA |
| Approx. Cu. Ft. Per Unit |
13.7 |
| Approx. Shipping Wt. Lbs. |
80 |
Contact us for warranty information |
