Features
- Powerful 15.0 AMP direct drive motor requires less maintenance and delivers 3,200 RPM
- Large cutting capacity for up to 8" crown molding (nested), 6-1/2" baseboard (vertical), and 15" crosscut at 90°
- Compact design with a patented 4-Steel Rail Sliding System further increases rigidity to produce superior cuts
- Independent laser indicates line-of-cut whether blade is turning or not, with on/off switch and micro-adjustments for precise "left-of-blade" or "right-of-blade" cutting
- Exclusive 6 linear ball bearings engineered to deliver smooth, solid, and adjustment-free "dead-on" accurate cuts
- Exclusive 5-1/2" tall dual sliding fence system features versatile upper and lower fence adjustments for more precise miter and bevel cuts
- Miters 0°-52° left and 0°-60° right, with positive stops at 0°, 15°, 22.5°, 31.6° and 45° (left and right)
- Patented retractable rear guard and triple gear system for increased vertical cutting capacity
- Bevels 0°-45° (left and right) with positive stops at 0°, 22.5°, 33.9° and 45° (left and right)
- Dual rear-handle bevel lock is easily accessible, with front and top facing scales for more precise bevel adjustments
Specifications
| Blade Diameter |
|
12" |
| Arbor |
|
1" |
| Crown Molding (nested) |
|
8" |
| Baseboard (vertical) |
|
6-1/2" |
| Max Cutting Capacity (Bevel/Miter) |
90°/90° |
3-5/8" x 15" |
| |
45°/45° L/R |
3-5/8" x 10-1/2" |
| No Load Speed |
|
3,200 RPM |
| AMPS (120V) |
|
15 |
| Dimensions (LxWxH) |
|
31-3/4" x 25-1/4" x 28-3/8" |
| Net Weight (lbs.) |
|
58.6 |
Includes
- 60T Carbide Tipped Blade (A-93712)
- Vertical Vise (122854-6)
- Dust Bag (122852-0)
- Triangular Rule (762001-3)
- Wrench #2.5 (783208-8)
- Wrench #13 (782232-8)
Contact us for warranty information |
