| Compound Cut 45x45 (L/L) |
2-3/4"x8-5/8" or 2-15/16"x7-1/16" |
| Amps |
15 |
| No-Load Speed |
3,800 RPM |
| Blade Diameter |
12" |
| Miter Cutting Range |
0-46 Degree L; 0-57 Degree R |
| Bevel Cutting Range |
Left & Right 0-45 Degree |
| Digital Display |
No |
| Laser Marker |
Yes |
| Saw Blade Drive System |
Poly V Belt & Gear |
| Splinter Guard |
Provided (Fixed) |
| Tool Dimension WxDxH |
23-7/16"x36-5/8"x27-15/16" |
| Tool Weight |
63.9 lbs |
| Cutting Capacities (HxW): |
.............. |
| 90 Degree Cross Cut |
4-3/16"x12-1/4" or 4-11/16"x10-3/16" |
| 45 Degree Miter (L/R) |
4-3/16"x8-5/8" or 4-11/16"x7-1/16" |
| 45 Degree Bevel (L) |
2-3/4"x12-1/4" or 2-15/16"x10-3/16" |
