Features
- Virtually dustless coring and chiseling with the new, optional dust removal system
- Improved performance in large coring applications up to 4" in masonry and unreinforced concrete
- Ruggedly built for a long lifetime
- Center of gravity close to the grip for good balance and handling
- Optimized for core drilling up to 4" at a fraction of the weight of comparable tools
- Drilling anchor and through-holes in concrete and masonry 1/2" - 4", recommended 5/8" in 1-1/2"
- Medium-duty demolition work
- Coring up to 4" diameter in masonry and concrete with TE-Y-BK core bits
- Coring in masonry with optional DD-TE-Y adapter HDMU core bits up to 4" diameter
Specifications
| Rotation speed gear 1 under no load |
350 rpm |
| Full hammering frequency |
3300 impacts/minute |
| Single impact energy |
5.4 ft-lbs |
| Hammer drill bits (optimum dia. range) |
5/8 - 1-9/16 in |
| Chiseling function |
Yes |
| Weight according EPTA-Procedure 01/2003 |
14.1 lb. |
| Active Vibration Reduction |
No |
| Active Torque Control |
No |
| Dust removal module |
TE DRS-Y (optional) |
| Max. chiseling performance |
55 in³/min |
Contact us for warranty information |
