SKU Porter Cable  690LR

Features

• 11 Amp motor producing 1-3/4 Peak HP
• 27,500 rpm single speed motor
• Cam lock lever enables simple coarse height adjustments and motor release (fixed base)
• Micrometer depth adjustor accurate to 1/128″
• Dust-sealed switch and sealed ball bearing construction enhance tool durability
• Precision machined aluminum motor housing and base
• Auto-release collet system allows for easy bit removal after use
• Collets included to accept 1/4″ and 1/2″ shank bits
• Under table stop prevents motor from inadvertently rotating out of base
• Overmolded grips for greater comfort in extended use

Specifications

Power:	120 VAC, 25-60 HZ
Amps:	11 Amps
Horsepower:	1-3/4 HP
No Load Speed:	27,500 rpm
Motor Diameter:	3-1/2 “
Collets:	1/4″ & 1/2″
Base:	5-3/4″ Round
Length:	12 “
Width:	5.5 “
Height:	8-5/8 “
Shipping Weight:	10 lbs
Weight:	8 lbs

Includes

• Fixed Base
• 1/4″ & 1/2″ collets
• Collet wrench
• Operating manual
